Product benefits
_ Environmental friendly: No hazardous materials
_ Easy to install, easy to maintain
Areas of application
_ Industrial roads, rural roads
_ Parking lots
_ Residential roads
Product feature
_ Long lifetime: up to 50,000 h
_ Type of protection: IP66
_ Module efficacy: up to 120 lm/W
_ Professional optical design: best use of light to the target area while not creating glare to driver and environment
Electrical Data
|
Operating mode
|
ECG
|
|
Nominal wattage
|
90 W
|
|
Connected load
|
90 W
|
|
Nominal voltage
|
100…240 V
|
|
Supply voltage
|
100…240 V
|
|
Mains frequency
|
50/60 Hz
|
Photometrical Data
|
Color temperature
|
3000K / 4000K / 5700K
|
|
Luminous Flux
|
10,800 lm
|
|
Color rendering index Ra
|
>70
|
Light Distribution Data
|
Beam angle
|
150 x 60 °
|
|
Light distribution
|
symmetric
|
Dimensions & Weight
|
Length
|
580.0 mm
|
|
Width
|
285.0 mm
|
|
Height
|
95.0 mm
|
|
Product weight
|
3.5 kg
|
Temperatures & Operating Conditions
Ambient temperature range -30…+50 °C
Capabilities
Type of installation side-entry
Certificates & Standards
|
Protection class
|
insulation class III (safety extra-low voltage)
|
|
Type of protection
|
IP66
|
