Product benefits
- Flexible power options: 70W…270W for different field of application
- Easy to install, easy to maintain
- Robust mechanical design for extreme outdoor conditions
- Environmental friendly: No hazardous materials
Areas of application
- City roads, industrial roads, parking lots
- Streets
Product features
- Long lifetime: up to 50,000 h
- High module efficacy: up to 140 lm/W
- Professional optical design: best use of light to the target area while not creating glare to driver and environment
- Type of protection: IP66
Electrical data
|
Operating mode
|
ECG
|
|
Nominal wattage
|
70 W
|
|
Connected load
|
70 W
|
|
Nominal voltage
|
220…240 V
|
|
Supply voltage
|
220…240 V
|
|
Mains frequency
|
50/60 Hz
|
Photometrical data
|
Color temperature
|
3000K / 4000K / 5700K
|
|
Color temperature [AGMP]
|
3000K / 4000K / 5700K
|
|
Luminous flux
|
9,800 lm
|
|
Color rendering index Ra
|
>70
|
|
Color rendering index Ra [AGMP]
|
>70
|
Light technical data
|
Beam angle
|
150 x 70 °
|
|
Light distribution
|
symmetric
|
Dimensions & weight
|
Length
|
545.0 mm
|
|
Width
|
279.0 mm
|
|
Height
|
128.0 mm
|
|
Product weight
|
5 kg
|
Colors & materials
|
Body material
|
diecast aluminium
|
|
Product color
|
metallic grey (RAL 9006)
|
|
Cover material
|
PC
|
Temperatures & operating conditions
Ambient temperature range -30…+50 °C
Additional product data
Type of cover lenses
Type of installation side-entry
Certificates & standards
